PED approved Nickel 200 Seamless Pipe and Alloy 201 Welded Tube suppliers
Nickel alloy tubes manufacturers produce the nickel alloys in different compositional makeups. The nickel alloy tubing contains material with most part being nickel and combined with other elements in the composition. There are many different types of nickel alloy seamless tubing such as Inconel, monel and other commercially pure nickel alloys. The tubes and pipes range from 1/8 inches to 30 inches in size. The nickel alloy pipe can be welded, electric resistant weld or seamless in Nickel 200 & 201 grades. The differences are in the production methods. The Nickel 200 pipes and tubes are used in various contexts and their types and dimensions vary. The nickel tube suppliers produce the pipes in round, rectangular, hydraulic or square types. These are some of the versatile tubing products produced by the nickel pipe suppliers that are used in high corrosive and sensitive applications. The welded nickel alloy tubes can be welded with ease to connectors, fittings and flanges. There are different pressure ratings for the Nickel 200 Tubes & pipes with different schedules. The high nickel alloy tubes are expensive, but are highly corrosion resistant. Therefore they are used in high end applications that absolutely require the nickel alloy tubes. The nickel alloy pipes and tubes can be replaced with other materials such as duplex steel when the absolute necessity is not there for the nickel alloy material.
Nickel Alloy Tubes Grades
Are you searching nearest Pure Nickel Tube suppliers? Manufacturer and exporter of Welded and Seamless Nickel Pipe in Mumbai, India
| ALLOY | TRADE NAME* | AMERICAN SPECIFICATION (ASTM) | UNS | W.NR. |
|---|---|---|---|---|
| 200 | Nickel 200 Pipes, Tubes | B/SB161 | N02200 | 2.4060 |
| 201 | Nickel 201 Pipes, Tubes | B/SB161 | N02201 | |
| 400 | Monel® 400 Pipes, Tubes | B/SB165 | N04400 | 2.436 |
| 600 | Inconel® 600 Pipes, Tubes | B/SB167 | N06600 | 2.4816 |
| 625 | Inconel® 625 Pipes, Tubes | B/SB444 | N06625 | 2.4856 |
| 825 | Incoloy® 825 Pipes, Tubes | B/SB423 | N08825 | 2.4858 |
| 800 | Incoloy® 800 Pipes, Tubes | B/SB407 | N08800 | 1.4876 |
| 800H | Incoloy® 800H Pipes, Tubes | B/SB407 | N08810 | 1.4958 |
| 800HT | Incoloy® 800HT Pipes, Tubes | B/SB407 | N08811 | 1.4959 |
* Refer Trademarks Notice
Some of the names used in our website are trade names and/or trademarks of specific manufacturers. Oshwin Overseas is not affiliated with any manufacturer(s). Supplies would be made to meet customer specifications from any of the available source(s).
Standard Specification for Nickel Alloy Tubing
Check ASME SB 161 Nickel 200 Pipe and thin wall UNS N02201 Seamless Tube Dimensions, OD and SWG chart, manufacturer and supplier of High Nickel Alloy Tubing in China
| MANUFACTURER OF | ASTM | ASME |
|---|---|---|
| Nickel Seamless Pipe and Tube | B161 | SB 161 |
| Seamless Nickel and Nickel Alloy, Condenser and Heat Exchanger Tubes | B163 | SB 163 |
| Nickel-Chromium-Aluminum Alloys (UNS N06699), Nickel-Chromium-Cobalt-Molybdenum Alloy (UNS N06617), Nickel-Chromium-Iron Alloys (UNS N06600, N06601, N06603, N06690, N06693, N06025, N06045, and N06696), Nickel-Chromium-Molybdenum-Copper Alloy (UNS N06235) Seamless Pipe and Tube, and Nickel-Iron-Chromium-Tungsten Alloy (UNS N06674) | B167 | SB 167 |
| Nickel-Copper Alloy (UNS N04400) Seamless Pipe and Tube | B165 | SB 165 |
| Nickel-Iron-Chromium-Molybdenum-Copper Alloy (UNS N08825, N08221, and N06845) Seamless Pipe and Tube | B423 | SB 423 |
| Seamless UNS N08020, UNS N08026, and UNS N08024 Nickel-Alloy Pipe and Tube | B729 | SB 729 |
| Nickel-Iron-Chromium Alloy Seamless Pipe and Tube | B407 | SB 407 |
| Nickel-Chromium-Molybdenum-Columbium Alloys (UNS N06625 and N06852) and Nickel-Chromium-Molybdenum-Silicon Alloy (UNS N06219) Pipe and Tube | B444 | SB 444 |
| Copper-Beryllium Alloy (UNS Nos. C17000 and C17200) Forgings and Extrusion | B570 | SB 570 |
| Nickel-Chromium-Molybdenum-Cobalt-Tungsten-Iron-Silicon Alloy (UNS N06333) Seamless Pipe and Tube | B722 | SB 722 |
| Nickel-Iron-Chromium-Silicon Alloys (UNS N08330 and UNS N08332) Seamless Pipe | B535 | SB 535 |
| Seamless Nickel and Nickel-Cobalt Alloy Pipe and Tube | B622 | SB 622 |
| UNS N08354, UNS N08925, and UNS N08926 Seamless Pipe and Tube | B677 | SB 677 |
| UNS N08029 & N08028 Seamless Pipe and Tube | B668 | SB 668 |
| Iron-Nickel-Chromium-Molybdenum Alloys (UNS N08367) Seamless Pipe and Tube | B690 | SB 690 |
Nickel Alloy Pipes Specifications
Manufacturer of Nickel Alloy Pipes & Tubes such as Instrument, Boiler & heat exchanger tubing in India, Best price of 2.4066 Nickel Tubes and UNS N02201 Pipe in Mumbai
| Nickel Pipe sizes range | 1/8”NB to 30”NB (Nominal Bore Diameter, ie the inner diameter of the pipe) |
| Manufacturer of | Seamless, Welded, Electric Resistance Welded (ERW), Fabricated, or LSAW |
| Form of | Round, Hydraulic, Rectangular, or Square |
| Marking | All Nickel Alloy pipes & tubes are marked as: Manufacturer Name, Standard, Grade, Thickness, OD, Length, Heat No. (Or according to the customer’s request.) |
| Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Pipe End | POE, TOE, TBE, BOE, BOE, PBE, BLE, BSE, BBE, BE, Plain End, Beveled End, and Treaded |
Standard Sizes available with Nickel pipe suppliers
| Products | Outside Diameter – OD | Wall Thickness – WT | Length | |||
| Inch | MM | Inch | MM | Ft max. | Mt max. | |
| Nickel Pipe | NPS1/2’’-6’’ | 21.34-168.3 | Sch10-Sch80 | 2.11-12.7 | 98’ | 30.00 |
Types of Nickel Alloy Pipes and Tubes
Nickel Alloy Tubes
Nickel Alloy Pipes
Nickel Redrawn Tubing
Pure Nickel Pipe
Nickel 200 Pipe
Nickel 201 Pipe
Nickel Alloy Boiler Tube
Nickel Alloy Heater Tube
Nickel Heat Exchanger Tube
Nickel Alloy Condenser Tube
Nickel Instrumentation Tube
Nickel Alloy Seamless Pipes
Nickel Alloy Welded Pipe
Nickel 200 Seamless Tube
Nickel 201 Seamless Tube
Corrosion Resistance Nickel Tubing
| Type |
|
| Applications | Resistance to various acids such as
|
Pure Nickel Pipe common standard
Most of the Nickel tubing suppliers stock the material in the following standards
| ASTM | USA | Ameirican Society of Mechanical Engineers |
| AISI | USA | Acronym of American Iron and Steel Institute |
| JIS | JAPAN | Japanese Industrial Standards |
| DIN | GERMANY | Deutsches Institut für Normung e.V. |
| UNS | USA | Unified Numbering System |
High temperature Nickel Alloy Tubes Specifications
| Nickel Tube sizes range | 3.35 mm OD To 101.6 mm OD |
| Manufacturer of | Seamless, Redrawn, Welded, Electric Resistance Welded (ERW), Fabricated, or LSAW |
| Form of | Round, Hydraulic, Rectangular, Coil, Hydraulic, Straight, ‘U’ bent and Square Tubes |
| Condition | Hot Finished & Cold Finished |
| American Standards (USA) | ASTM B622, ASTM B161 ASTM B163, (Seamless Nickel Alloy tubing), ASTM B730 (Welded Nickel Alloy Tubing) |
| Nickel Alloy Tubes length | Single Random, Double Random, Standard & Cut length |
| Swg & Bwg | 10 Swg., 14 Swg., 12 Swg., 18 Swg., 16 Swg., 20 Swg. |
| Value Added Service | Draw & Expansion as per required Length and Size, Annealed, Polish (Electro & Commercial) & Pickled Bending, Machining Etc. |
| Uses & Application | Gas Tube, Oil Tube, Fluid Tube, Boiler and Heatexchanger |
| Finish | Polished, BA (Bright & Annealed), MF, AP (Annealed & Pickled) |
| Test Reports & Certificates |
|
Standard Sizes available with Nickel tubing suppliers
| Products | Outside Diameter – OD | Wall Thickness – WT | Length | |||
| Inch | MM | Inch | MM | Ft max. | Mt max. | |
| Tube | 1/2’’-3’’ | 12.0-76.2 | 0.02’’-0.5’’ | 0.5-12.0 | 105’ | 32.00 |
Nickel Tubing sizes
| WALL THICKNESS (WT) | NICKEL TUBE SIZE CHART ( O.D.) |
|---|---|
| .010 | 1/16″ , 1/8″ , 3/16″ |
| .020 | 1/16″ , 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ |
| .012 | 1/8″ |
| .016 | 1/8″ , 3/16″ |
| .028 | 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 3/4″ , 1″ , 1 1/2″ , 2″ |
| .035 | 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 7/16″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″ |
| .049 | 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/8″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″ |
| .065 | 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 3/4″ , 2″ , 2 1/2″ , 3″ |
| .083 | 1/4″ , 3/8″ , 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 7/8″ , 2″ , 2 1/2″ ,3″ |
| .095 | 1/2″ , 5/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ |
| .109 | 1/2″ , 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ |
| .120 | 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 2 1/4″ , 2 1/2″ , 3″ |
| .125 | 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 3″ , 3 1/4″ |
| .134 | 1″ |
| .250 | 3″ |
| .375 | 3 1/2″ |
ASTM B161 UNS N02200 Nickel 200 Pipe Equivalent Grades
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Nickel 200 Pipe | N02200 | 2.4066 | N-100M | Ni 99.2 | NW 2200 | NA 11 | НП-2 |
ASTM B161 UNS N02201 Nickel 201 Pipe Equivalent Grades
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Nickel 201 Pipe | N02201 | 2.4068 | – | LC-Ni 99 | NW 2201 | NA 12 | НП-2 |
ASTM B163 UNS N02200 Nickel 200 Tube
| NICKEL BASED ALLOYS | TUBE TYPE | DIMENSION (MM) |
|---|---|---|
| NICKEL 200 (99.0 Ni min) | Tubing; cold drawn, annealed, seamless | 16.0 x 1.5 |
| NICKEL 200/201 (99.0 Ni min) | Tubing; cold drawn, annealed | 33.4 x 3.38 (1″nb sch40s) |
| NICKEL 200/201 (99.0 Ni min) | Tubing; cold drawn, annealed | 48.26 x 2.77 (1½”nb sch10s) |
| NICKEL 200/201 (99.0 Ni min) | Tubing; cold drawn, annealed | 60.33 x 2.77 (2″nb Sch10s) |
| NICKEL 200/201(99.0 Ni min) | Tubing; cold drawn, annealed | 60.33 x 3.91 (2″nb sch40s) |
| NICKEL 200/201 (99.0 Ni min) | Tubing; cold drawn, annealed | 88.9 x 3.05 (3″nb Sch10s) |
| NICKEL 200/201 (99.0 Ni min) | Tubing; cold drawn, annealed | 114.3 x 3.05 (4″nb Sch10s) |
ASTM B163 UNS N02201 Nickel 201 Tube
| NICKEL BASED ALLOYS | TUBE TYPE | DIMENSION (MM) |
|---|---|---|
| Alloy 201 (99.0 Ni min) | Tube; seamless, annealed | 6.0 x 1.0 |
| Alloy 201 (99.0 Ni min) | Tube; seamless, annealed | 8.0 x 1.0 |
| Alloy 201 (99.0 Ni min) | Tube; cold drawn, annealed, seamless | 9.53 x 1.65 (3/8″ x 0.065″) |
| Alloy 201 (99.0 Ni min) | Tube; cold drawn, seamless, annealed | 10.0 x 1.0 |
| Alloy 201 (99.0 Ni min) | Tube; seamless, annealed | 12.7 x 0.9 (½” x 0.035″) |
| Alloy 201 (99.0 Ni min) | Tube; seamless, annealed | 12.7 x 1.2 (½” x 0.049″) |
| Alloy 201 (99.0 Ni min.) | Tube; cold drawn, annealed, seamless | 13.72 x 2.24 (¼”nb sch40s) |
| Alloy 201 (99.0 Ni min.) | Tube; cold drawn, seamless, annealed | 13.72 x 3.02 (¼”nb sch80s) |
| Alloy 201 (99.0 Ni min) | Tube; annealed, seamless | 14.0 x 1.0 |
| Alloy 201 (99.0 Ni min) | Tube; seamless, annealed | 21.34 x 2.77 (½”nb sch40s) |
| Alloy 201 (99.0 Ni min) | Tube; cold drawn, annealed | 26.67 x 2.11 (¾”nb sch10s) |
| Alloy 201 (99.0 Ni min) | Tube; cold drawn, annealed | 26.67 x 2.87 (¾”nb sch40s) |
| Alloy 201 (99.0 Ni min) | Tube; cold drawn | 48.26 x 6.35 |
Nickel Alloy Tubes manufacturers
- Sumitomo Metals, Japan
- Schoeller Bleckmann, Austria
- Nippon Steel Corporation, Japan
- Seah Steel Corporation, Korea
- Sanyo Special Steel, Japan
- Tubacex Tubos Inoxidables S.A., Spain
- Kobe Special Tube, Japan
Nickel Seamless Tube price in China
Nickel 200/ 201 Tube Price per kg ex Tianjin port
| ORIGIN OF MATERIAL | INR RS (PRICE PER KG) |
US $ (PRICE PER KG) |
EURO € (PRICE PER KG) |
|---|---|---|---|
| India | Rs 2500/- | $36 | €30 |
| Japan | Rs 2900/- | $42 | €37 |
| Europe/ UK | Rs 3200/- | $47 | €41 |
| USA | Rs 3400/- | $50 | €43 |
For bulk orders or emergency delivery please contact Alloyworld.
Nickel Based Alloy Pipe Composition
| NICKEL ALLOY PIPES/ TUBES | NI | C | MO | MN | SI | FE | P | S | CU | CR |
|---|---|---|---|---|---|---|---|---|---|---|
| Alloy 200 Pipe/ Tube | 99.0 min | 0.15 max | – | 0.35 max | 0.1 max | 0.4 max | – | 0.01 max | 0.25 max | – |
| Alloy 201 Pipe/ Tube | Balance | 0.15 max | – | 0.35 max | 0.35 max | 0.40 max | – | 0.01 max | 0.25 max | – |
Mechanical Properties of Nickel Pipe
| Nickel Based Alloys | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| Alloy 200/ 201 Pipe | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 21500 , MPa – 148 | Psi – 67000 , MPa – 462 | 45 % |
Nickel Alloy Pipe schedule chart
| PIPE SIZE (NPS) | OD | ID | SCHEDULES | WALL | APPROX LBS PER FT |
|---|---|---|---|---|---|
| 1/8″ | .405 | .307 | 10, 10S | .049 | .1863 |
| .269 | 40, STD, 40S | .068 | .2447 | ||
| .215 | 80, XS, 80S | .095 | .3145 | ||
| 1/4″ | .540 | .410 | 10, 10S | .065 | .3297 |
| .364 | 40, STD, 40S | .088 | .4248 | ||
| .302 | 80, XS, 80S | .119 | .5351 | ||
| 3/8″ | .675 | .545 | 10, 10S | .065 | .4235 |
| .493 | 40, STD, 40S | .091 | .5676 | ||
| .423 | 80, XS, 80S | .126 | .7388 | ||
| 1/2″ | .840 | .674 | 10, 10S | .083 | .6710 |
| .622 | 40, STD, 40S | .109 | .8510 | ||
| .546 | 80, XS, 80S | .147 | 1.088 | ||
| .466 | 160 | .187 | 1.304 | ||
| .252 | XX | .294 | 1.714 | ||
| 3/4″ | 1.050 | .884 | 10, 10S | .083 | .8572 |
| .824 | 40, STD, 40S | .113 | 1.131 | ||
| .742 | 80, XS, 80S | .154 | 1.474 | ||
| .614 | 160 | .218 | 1.937 | ||
| .434 | XX | .308 | 2.441 | ||
| 1″ | 1.315 | 1.097 | 10, 10S | .109 | 1.404 |
| 1.049 | 40, STD, 40S | .133 | 1.679 | ||
| .957 | 80, XS, 80S | .179 | 2.172 | ||
| .815 | 160 | .250 | 2.844 | ||
| .599 | XX | .358 | 3.659 | ||
| 1 1/4″ | 1.660 | 1.442 | 10, 10S | .109 | 1.806 |
| 1.380 | 40, STD, 40S | .140 | 2.273 | ||
| 1.278 | 80, XS, 80S | .191 | 2.997 | ||
| 1.160 | 160 | .250 | 3.765 | ||
| .896 | XX | .382 | 5.214 | ||
| 1 1/2″ | 1.900 | 1.682 | 10, 10S | .109 | 2.085 |
| 1.610 | 40, STD, 40S | .145 | 2.718 | ||
| 1.500 | 80, XS, 80S | .200 | 3.631 | ||
| 1.337 | 160 | .281 | 4.859 | ||
| 1.100 | XX | .400 | 6.408 | ||
| 2″ | 2.375 | 2.157 | 10, 10S | .109 | 2.638 |
| 2.067 | 40, STD, 40S | .154 | 3.853 | ||
| 1.939 | 80, XS, 80S | .218 | 5.022 | ||
| 1.689 | 160 | .344 | 7.462 | ||
| 1.503 | XX | .436 | 9.029 | ||
| 2 1/2″ | 2.875 | 2.635 | 10, 10S | .120 | 3.531 |
| 2.469 | 40, STD, 40S | .203 | 5.793 | ||
| 2.323 | 80, XS, 80S | .276 | 7.651 | ||
| 2.125 | 160 | .375 | 10.01 | ||
| 1.771 | XX | .552 | 13.70 | ||
| 3″ | 3.500 | 3.260 | 10, 10S | .120 | 4.332 |
| 3.068 | 40, STD, 40S | .216 | 7.576 | ||
| 2.900 | 80, XS, 80S | .300 | 10.25 | ||
| 2.624 | 160 | .438 | 14.32 | ||
| 2.300 | XX | .600 | 18.58 | ||
| 3 1/2″ | 4.000 | 3.760 | 10, 10S | .120 | 4.937 |
| 3.548 | 40, STD, 40S | .226 | 9.109 | ||
| 3.364 | 80, XS, 80S | .318 | 12.51 | ||
| 2.728 | XX | .636 | 22.85 | ||
| 4″ | 4.500 | 4.260 | 10, 10S | .120 | 5.613 |
| 4.026 | 40, STD, 40S | .237 | 10.790 | ||
| 3.826 | 80, XS, 80S | .337 | 14.98 | ||
| 3.624 | 120 | .438 | 19 | ||
| 3.438 | 160 | .531 | 22.51 | ||
| 3.152 | XX | .674 | 27.54 | ||
| 4 1/2″ | 5.000 | 4.506 | STD, 40S | .247 | 12.54 |
| 4.290 | XS, 80S | .355 | 17.61 | ||
| 5″ | 5.563 | 5.295 | 10, 10S | .134 | 7.770 |
| 5.047 | 40, STD, 40S | .258 | 14.62 | ||
| 4.813 | 80, XS, 80S | .375 | 20.78 | ||
| 4.563 | 120 | .500 | 27.04 | ||
| 4.313 | 160 | .625 | 32.96 | ||
| 4.063 | XX | .750 | 38.55 | ||
| 6″ | 6.625 | 6.357 | 10, 10S | .134 | 9.290 |
| 6.065 | 40, STD, 40S | .280 | 18.97 | ||
| 5.761 | 80, XS, 80S | .432 | 28.57 | ||
| 5.501 | 120 | .562 | 35.39 | ||
| 5.189 | 160 | .719 | 43.35 | ||
| 4.897 | XX | .864 | 53.16 | ||
| 8″ | 8.625 | 8.329 | 10, 10S | .148 | 13.40 |
| 8.125 | 20 | .250 | 22.36 | ||
| 8.071 | 30 | .277 | 24.70 | ||
| 7.981 | 40, STD, 40S | .322 | 28.55 | ||
| 7.813 | 60 | .406 | 35.64 | ||
| 7.625 | 80, XS, 80S | .500 | 43.39 | ||
| 7.439 | 100 | .594 | 50.95 | ||
| 7.189 | 120 | .719 | 61.71 | ||
| 7.001 | 140 | .812 | 67.76 | ||
| 6.813 | 160 | .906 | 74.79 | ||
| 6.875 | XX | .875 | 72.42 | ||
| 10″ | 10.750 | 10.420 | 10, 10S | .165 | 18.65 |
| 10.250 | 20 | .250 | 28.04 | ||
| 10.136 | 30 | .307 | 34.24 | ||
| 10.020 | 40, STD, 40S | .365 | 40.48 | ||
| 9.750 | 60, XS, 80S | .500 | 54.74 | ||
| 9.564 | 80 | .594 | 64.43 | ||
| 9.314 | 100 | .719 | 77.03 | ||
| 9.064 | 120 | .844 | 82.29 | ||
| 8.750 | 140, XX | 1.000 | 104.1 | ||
| 8.500 | 160 | 1.125 | 115.6 | ||
| 12″ | 12.750 | 12.390 | 10, 10S | .180 | 24.16 |
| 12.250 | 20 | .250 | 33.38 | ||
| 12.090 | 30 | .330 | 43.77 | ||
| 12.000 | STD, 40S | .375 | 49.56 | ||
| 11.938 | 40 | .406 | 53.52 | ||
| 11.750 | XS, 80S | .500 | 65.42 | ||
| 11.626 | 60 | .562 | 73.15 | ||
| 11.376 | 80 | .688 | 88.63 | ||
| 11.064 | 100 | .844 | 107.9 | ||
| 10.750 | 120, XX | 1.000 | 125.5 | ||
| 10.500 | 140 | 1.125 | 136.7 | ||
| 10.126 | 160 | 1.312 | 150.3 | ||
| 14″ | 14.000 | 13.624 | 10S | .188 | 27.73 |
| 13.500 | 10 | .250 | 36.71 | ||
| 13.375 | 20 | .312 | 45.61 | ||
| 13.250 | 30, STD, 40S | .375 | 54.57 | ||
| 13.124 | 40 | .438 | 63.44 | ||
| 13.000 | XS, 80S | .500 | 72.09 | ||
| 12.814 | 60 | .594 | 85.05 | ||
| 12.500 | 80 | .750 | 106.1 | ||
| 12.124 | 100 | .938 | 130.9 | ||
| 11.814 | 120 | 1.09 | 150.8 | ||
| 11.500 | 140 | 1.250 | 170.2 | ||
| 11.188 | 160 | 1.406 | 189.1 | ||
| 16″ | 16.000 | 15.624 | 10S | .188 | 31.75 |
| 15.500 | 10 | .250 | 42.05 | ||
| 15.375 | 20 | .312 | 52.27 | ||
| 15.250 | 30, STD, 40S | .375 | 62.58 | ||
| 15.000 | 40, XS, 80S | .500 | 82.77 | ||
| 14.688 | 60 | .656 | 107.5 | ||
| 14.314 | 80 | .844 | 136.6 | ||
| 13.938 | 100 | 1.031 | 164.8 | ||
| 13.564 | 120 | 1.22 | 192.4 | ||
| 13.124 | 140 | 1.438 | 223.6 | ||
| 12.814 | 160 | 1.594 | 245.3 | ||
| 18″ | 18.000 | 17.624 | 10S | .188 | 35.76 |
| 17.500 | 10 | .250 | 47.99 | ||
| 17.375 | 20 | .312 | 58.94 | ||
| 17.250 | STD, 40S | .375 | 70.59 | ||
| 17.124 | 30 | .438 | 82.15 | ||
| 17.000 | XS, 80S | .500 | 93.45 | ||
| 16.876 | 40 | .562 | 104.7 | ||
| 16.500 | 60 | .750 | 138.2 | ||
| 16.126 | 80 | .938 | 170.9 | ||
| 15.688 | 100 | 1.156 | 208.0 | ||
| 15.250 | 120 | 1.38 | 244.10 | ||
| 14.876 | 140 | 1.562 | 274.20 | ||
| 14.438 | 160 | 1.781 | 308.5 | ||
| 20″ | 20.000 | 19.564 | 10S | .218 | 48.05 |
| 19.500 | 10 | .250 | 52.73 | ||
| 19.250 | 20, STD, 40S | .375 | 78.6 | ||
| 19.000 | 30, XS, 80S | .500 | 104.10 | ||
| 18.812 | 40 | .594 | 123.10 | ||
| 18.376 | 60 | .812 | 155.40 | ||
| 17.938 | 80 | 1.031 | 208.90 | ||
| 17.438 | 100 | 1.281 | 256.10 | ||
| 17.000 | 120 | 1.500 | 296.40 | ||
| 16.500 | 140 | 1.750 | 341.10 | ||
| 16.064 | 160 | 1.969 | 379.20 | ||
| 24″ | 24.000 | 23.500 | 10, 10S | .250 | 63.41 |
| 23.250 | 20, STD, 40S | .375 | 96.42 | ||
| 23.000 | XS, 80S | .500 | 125.50 | ||
| 22.876 | 30 | .562 | 140.70 | ||
| 22.626 | 40 | .688 | 171.30 | ||
| 22.064 | 60 | .969 | 238.40 | ||
| 21.564 | 80 | 1.219 | 296.80 | ||
| 20.938 | 100 | 1.531 | 357.40 | ||
| 20.376 | 120 | 1.812 | 429.40 | ||
| 19.876 | 140 | 2.062 | 483.10 | ||
| 19.314 | 160 | 2.344 | 542.10 | ||
| 30″ | 30.000 | 29.376 | 10, 10S | .312 | 98.93 |
| 29.250 | STD, 40S | .375 | 118.65 | ||
| 29.000 | 20, XS, 80S | .500 | 157.53 | ||
| 28.750 | 30 | .625 | 196.06 | ||
| 36″ | 36.000 | 35.376 | 10 | .312 | 118.92 |
| 35.250 | STD, 40S | .375 | 142.68 | ||
| 35.000 | XS, 80S | .500 | 189.57 | ||
| 34.750 | 30 | .625 | 235.13 | ||
| 48″ | 48.000 | 47.250 | STD, 40S | .375 | 190.74 |
| 47.000 | XS, 80S | .500 | 253.65 |
